Korea design competition SPL digital mono 5000W car amplifier

Ask Lasest Price
Brand Name :	XHR
Model Number :	XHR-5000.1D（2）
Price :	US$450
Payment Terms :	T/T,Western Union,PAYPAL
Supply Ability :	100%
Delivery Time :	25 days

Add to Cart

Product Details
Company Profile

Korea design competition SPL digital mono 5000W car amplifier

Korea design competition SPL digital mono 5000W car amplifier

Model:HA-5000D1

Channel: 1 CH

Type:CLASS-D Car audio amplifier.

Input DC :10V-16V

Power output:

RMS 1Ω*5000W,MAX 1Ω*10000W

RMS 2Ω*2500W, MAX 2Ω*5000W

RMS 4Ω*1800W,MAX 4Ω*3500W

T.H.D+N:≤0.15

S/N :≥90dB

Damping Factor+350

Subsonig :15Hz-50Hz

Lowpass:40Hz-250Hz

BassBoost:0dB-18dB

Phase:0°-180°

PCB:FR4

Input Sensitivity:200mV-6V

Dimension:850*260*55MM

Weight:19kg

Class-D mono (Digital) car amplifier

Super-efficient Class-D PWM design runs much cooler

High-efficiency MOSFET power supply

Platinum Plated Heavy Duty Power & Speaker Terminals

Wired Remote Controller

Soft delayed remote turn-on / off circuitry

Fully 1Ω stable operation (Mono only),Subsonic filter (Mono only)

Variable phase shift (Mono only),Heavy-duty heatsink

Oversized capacitor tanks

Adjustable low gain control,Power / Protect LED indicators.

Purduct features:

Short circuit,thermal,overload,DC offset protection.

Features:

lRobust design based on Heavy duty gloss black with brushed accents.

lAdvanced Class-D Technology to reach high power output.

lCool blue led lighting indicated terminal to easy install

lFull range, Combine and Mono block subwoofer amplifier

lDouble side circuit board with precision SMT

l0-18dB at 45Hz Bass Boost

lPhase adjustable for 3CH, 5CH and Mono Blocks from 0-180 degrees.

lLine input from 0.2V to 4 V

lMono Block power output built on 1 ohm stable

lHuge power terminal can hold 2#AWG( American Wire Gauge ) cable since 1600W Power Block

lDash mount remote gain include under voltage, over current, voltage, temperature

Packaging Details

Unit Type:piece

Package Weight:18.700kg (58.86lb.)

Package Size:89cm x 31cm x 8cm (35.04in x 12.20in x 3.15in)
